Crompton CPT3 60 075 3300-6 _ Control Power Transformer , Primary Voltage - 3300, Ratio at 120V - 27.50
Write a Review
Write a Review
Crompton
Crompton CPT3 60 075 3300-6 _ Control Power Transformer , Primary Voltage - 3300, Ratio at 120V - 27.50
$1,099.94
- Brand
- Crompton
- SKU:
- CPT3-60-075-3300-6
- Availability:
- Y
Crompton CPT3 60 075 3300-6 _ Control Power Transformer , Primary Voltage - 3300, Ratio at 120V - 27.50
APPLICATION:
To provide power in Motor Control centers and Distribution Switchgear
FREQUENCY:
50/60 Hz.
INSULATION LEVEL:
6.9 kV, 60 kV BIL. full wave
THERMAL RATING:
At 30°C. amb.
APPROXIMATE WEIGHT:
25 lbs.
Features:
- Primary and secondary terminal are brass screws No. 1032 with one flat washer and lockwasher.
- Transformer winding is vacuum encapsulated in polyurethane resin with temperature insulation class of 105°C
- Plated steel Mount ing base
- For indoor use
Specifications:
- Catalog Number: CPT3 60 075 3300-6
- Primary Voltage: 3300
- Ratio at 120V: 27.5
- Secondary Voltage: 120/240
- Frequency in Hz: 50/60
- Thermal Rating: 0.75 kVA
- Weight in lbs: 25
Specifications Sheet:
Datasheet.pdf0 Reviews Hide Reviews Show Reviews
Crompton
Crompton CPT3 60 075 3300-5 _ Control Power Transformer , Primary Voltage - 3300, Ratio at 120V - 30.00
$1,099.94
Crompton CPT3 60 075 3300-5 _ Control Power Transformer , Primary Voltage - 3300, Ratio at 120V - 30.00APPLICATION: To provide power in Motor Control centers and Distribution Switchgear FREQUENCY:...
Crompton
Crompton CPT3 60 2 3300-5 _ Medium Voltage Control Power Transformer , Primary Voltage - 3300, Ratio at 120V - 30
