Yokogawa 205104 Miniature Portable DC Ammeter, 0.3/1/3/10/30 A, 0.14/0.04/0.014/0.004/0.001 ¦
Write a Review
Write a Review
Yokogawa
Yokogawa 205104 Miniature Portable DC Ammeter, 0.3/1/3/10/30 A, 0.14/0.04/0.014/0.004/0.001 ¦
$417.90
- Brand
- Yokogawa
- SKU:
- 205104
Yokogawa 205104 Miniature Portable DC Ammeter, 0.3/1/3/10/30 A, 0.14/0.04/0.014/0.004/0.001 ¦
Yokogawa 205104 Miniature Portable DC Ammeter, 0.3/1/3/10/30 A, 0.14/0.04/0.014/0.004/0.001 ¦
The Yokogawa 205104 Miniature Portable DC Ammeter, 0.3/1/3/10/30 A, 0.14/0.04/0.014/0.004/0.001¦ is a JIS C 1102-2 Class 1.0 instrument. The taut-band suspension system is used in the moving parts to eliminate friction and provide strong resistance to shock impact. This instrument is functional and compact, making it suitable for labs at research centers and schools. The 205104 is also very useful for factory setups in which numerous instruments are arranged on a small tabletop area, and is small enough to be carried for maintenance service use.
Product Features:
- Useful for both high-sensitivity and large-volume measurements: DC: 30 A~30 A, 0.3 V~300 V
- Taut-band suspension system eliminates friction and provides strong resistance to shock impact
- Small and lightweight, with easy-to-read mirrored scale
- Useful for both high-sensitivity and large-volume measurements
- Maximum scale value: 0.3/1/3/10/30 A DC
- Approximate internal resistance, consumed power: 0.14/0.04/0.014/0.004/0.001¦
- Operating principle : Permanent magnet moving coil type
- Class: JIS C 1102 Equivalent to Class 1.0
- Scale length: Approximately 88 mm (deflection angle: 90°)
- Needle: Bladed needle (red)
- Operating position: Horizontal
- Rated frequency: 50/60 Hz
- Operating temperature and humidity ranges : 0 to 40°C, 25 to 80% RH
Included:
- 1 - User Manual
