Yokogawa 205101 Miniature Portable DC Ammeter, 30/100/300/1000/3000 µA, 5/6.8/2.8/0.9/0.3 k¦
$417.90
- Brand
- Yokogawa
- SKU:
- 205101
Yokogawa 205101 Miniature Portable DC Ammeter, 30/100/300/1000/3000 µA, 5/6.8/2.8/0.9/0.3 k¦
Yokogawa 205101 Miniature Portable DC Ammeter, 30/100/300/1000/3000 µA, 5/6.8/2.8/0.9/0.3 k¦
The Yokogawa 205101 Miniature Portable DC Ammeter, 30/100/300/1000/3000 µA, 5/6.8/2.8/0.9/0.3 k¦ is a JIS C 1102-2 Class 1.0 instrument. The taut-band suspension system is used in the moving parts to eliminate friction and provide strong resistance to shock impact. This instrument is functional and compact, making it suitable for labs at research centers and schools. The 205101 is also very useful for factory setups in which numerous instruments are arranged on a small tabletop area, and is small enough to be carried for maintenance service use.
Product Features:
- Useful for both high-sensitivity and large-volume measurements: DC: 30 A~30 A, 0.3 V~300 V
- Taut-band suspension system eliminates friction and provides strong resistance to shock impact
- Small and lightweight, with easy-to-read mirrored scale
- Useful for both high-sensitivity and large-volume measurements
- Maximum scale value: 30/100/300/1000/3000 μA DC
- Approximate internal resistance, consumed power: 5/6.8/2.8/0.9/0.3 k¦
- Operating principle : Permanent magnet moving coil type
- Class: JIS C 1102 Equivalent to Class 1.0
- Scale length: Approximately 88 mm (deflection angle: 90°)
- Needle: Bladed needle (red)
- Operating position: Horizontal
- Rated frequency: 50/60 Hz
- Operating temperature and humidity ranges : 0 to 40°C, 25 to 80% RH
Included:
- 1 - User Manual
0 Reviews Hide Reviews Show Reviews
Yokogawa
Yokogawa 201132 Portable DC Ammeter, 10/30/100/300 µA, 6.8/6/8/2.5/0.88 k¦
$796.00
Yokogawa 201132 Portable DC Ammeter, 10/30/100/300 µA, 6.8/6/8/2.5/0.88 k¦The Yokogawa 201132 Portable DC Ammeter, 10/30/100/300 µA, 6.8/6/8/2.5/0.88 k¦ is a moving coil type of instruments using a...
Yokogawa
Yokogawa 205105 Miniature Portable DC Voltmeter, 0.3/1/3/10/30 V, 100 µA (10 k¦/V)
$417.90
Yokogawa 205105 Miniature Portable DC Voltmeter, 0.3/1/3/10/30 V, 100 µA (10 k¦/V)The Yokogawa 205105 Miniature Portable DC Voltmeter, 0.3/1/3/10/30 V, 100 µA (10 k¦/V) is a JIS C 1102-2 Class 1.0...
Yokogawa
Yokogawa 205120 Miniature Portable DC Voltmeter, ± 3/10/30/100/300 V, 100 µA (10 k¦/V)
$477.60
Yokogawa 205120 Miniature Portable DC Voltmeter, ± 3/10/30/100/300 V, 100 µA (10 k¦/V)The Yokogawa 205120 Miniature Portable DC Voltmeter, ± 3/10/30/100/300 V, 100 µA (10 k¢¦/V) is a JIS C 1102-2...
Yokogawa
Yokogawa 205106 Miniature Portable DC Voltmeter, 3/10/30/100/300 V, 100 µA (10 k¦/V)
$417.90
Yokogawa 205106 Miniature Portable DC Voltmeter, 3/10/30/100/300 V, 100 µA (10 k¦/V)The Yokogawa 205106 Miniature Portable DC Voltmeter, 3/10/30/100/300 V, 100 µA (10 k¦/V) is a JIS C 1102-2 Class...
Yokogawa
Yokogawa 201131 Portable DC Ammeter, 3/10/30/100 µA, 5.1/18.3/7.7/2.5 k¦
