Absolute Process Instruments T16L4 _ transmitter. Fully isolated.

$399.00

Brand: Absolute Process Instruments
SKU:: T16L4
UPC:

Absolute Process Instruments T16L4 _ transmitter. Fully isolated.

Cecomp Electronics, T16L4, ThermoPro® Loop Powered Temperat

Current Stock:

Quantity:

Adding to cart… The item has been added

Add to Wish List

Description

0 Reviews

Absolute Process Instruments T16L4 _ transmitter. Fully isolated.
Cecomp Electronics, T16L4, ThermoPro® Loop Powered Temperature Transmitter, 4" Fixed Probe Length
Features:
100 Î© Platinum RTD
316 Stainless Steel Probe
2 wire 4-20 mA Output with Programmable Range
-58.0°F to 392.0°F or -50.0°C to 200.0°C
NEMA 4X Housing
User-programmable 4-20 mA output range
Selectable °F or °C
Pass code protected setup and calibration
Specifications Table:
Range 58.0 to 392.0°F or 50.0 to 200.0°C, selectable
Resolution 0.1°F or 0.1°C resolution
Accuracy Includes linearity error and ±1 LSD 11-point linearization
±0.7°C at 50°C
±0.4°C at 0°C
±0.9°C at 100°C
±1.4°C at 200°C
Display
4 readings per second nominal display update rate
4 digit LCD, 0.5" H
5 character 0.25" H alphanumeric
Low battery voltage indication(ALARM1 under range indication on display, ALARM2 over range indication on display)
Sensor
IEC-751 Class B 100 Î© Platinum RTD, 0.00385 alpha curve 1 /2" NPT male, 316L stainless steel
All wetted parts are 316L stainless steel
Probe pressure rating: 5000 psi max.
Probes are welded to hex fitting
Analog Output
12,000 count 4-20 mA output
Updated approximately 4 times per second
Temperature range configurable to correspond to 4-20 mA output
Configurable for upscale or downscale burnout
Controls and Functions
3 button front keypad for setup, calibration, and configuration.
User-defined pass codes to prevent unauthorized changes.
Pass code required for configuration and calibration.
Output Test Function When TEST button is held loop current and display are set to test level, independent of temperature input, to allow testing of system operation. Test level is user set. Output test function can be pass code protected
Calibration
User settable pass code required to enter calibration mode
Zero and span temperature calibration
Non-interactive zero, span, and linearity, ±10% of range
Weight
Product: 12 ounces (approximately)
Shipping: 1 pound (approximately)
Housing Materials ABS/polycarbonate NEMA 4X case, rear gasket, polycarbonate label, aluminum sensor block
Storage Temperature 40 to 203°F (40 to 95°C)
Operating Range 4 to 185°F (20 to 85°C) at housing
Cable Length 4"
Power
Any DC supply/loop resistance that maintains 8 to 32 VDC at gauge terminals
Reverse polarity protected
3 ft long, 2-conductor 22 AWG cable

Write a Review

0 Reviews Hide Reviews Show Reviews

Range	58.0 to 392.0°F or 50.0 to 200.0°C, selectable
Resolution	0.1°F or 0.1°C resolution
Accuracy	Includes linearity error and ±1 LSD 11-point linearization ±0.7°C at 50°C ±0.4°C at 0°C ±0.9°C at 100°C ±1.4°C at 200°C
Display	4 readings per second nominal display update rate 4 digit LCD, 0.5" H 5 character 0.25" H alphanumeric Low battery voltage indication(ALARM1 under range indication on display, ALARM2 over range indication on display)
Sensor	IEC-751 Class B 100 Î© Platinum RTD, 0.00385 alpha curve 1 /2" NPT male, 316L stainless steel All wetted parts are 316L stainless steel Probe pressure rating: 5000 psi max. Probes are welded to hex fitting
Analog Output	12,000 count 4-20 mA output Updated approximately 4 times per second Temperature range configurable to correspond to 4-20 mA output Configurable for upscale or downscale burnout
Controls and Functions	3 button front keypad for setup, calibration, and configuration. User-defined pass codes to prevent unauthorized changes. Pass code required for configuration and calibration.
Output Test Function	When TEST button is held loop current and display are set to test level, independent of temperature input, to allow testing of system operation. Test level is user set. Output test function can be pass code protected
Calibration	User settable pass code required to enter calibration mode Zero and span temperature calibration Non-interactive zero, span, and linearity, ±10% of range
Weight	Product: 12 ounces (approximately) Shipping: 1 pound (approximately)
Housing Materials	ABS/polycarbonate NEMA 4X case, rear gasket, polycarbonate label, aluminum sensor block
Storage Temperature	40 to 203°F (40 to 95°C)
Operating Range	4 to 185°F (20 to 85°C) at housing
Cable Length	4"
Power	Any DC supply/loop resistance that maintains 8 to 32 VDC at gauge terminals Reverse polarity protected 3 ft long, 2-conductor 22 AWG cable
