Absolute Process Instruments T16ADA2S _ transmitter. Fully isolated.

$489.00

Brand: Absolute Process Instruments
SKU:: T16ADA2S
UPC:

Absolute Process Instruments T16ADA2S _ transmitter. Fully isolated.

Cecomp Electronics, T16ADA2S, ThermoPro® Temperature Ala

Current Stock:

Quantity:

Adding to cart… The item has been added

Add to Wish List

Description

0 Reviews

Absolute Process Instruments T16ADA2S _ transmitter. Fully isolated.
Cecomp Electronics, T16ADA2S, ThermoPro® Temperature Alarm, 2.5" Length Spring-Loaded for Thermowell Probe
Features:
100 Î© Platinum RTD
316 Stainless Steel Probe
Programmable SPDT Relays
-58.0°F to 392.0°F or -50.0°C to 200.0°C
NEMA 4X Housing
Spring-Loaded Versions for Thermowells
User-programmable setpoints
User configurable relay operation
Pass code protected setup and calibration
Specifications Table:
Range 58.0 to 392.0°F or 50.0 to 200.0°C, selectable
Resolution 0.1 degree resolution
Typical Accuracy Includes linearity error and ±1 LSD 11-point linearization
±0.7°C at 50°C
±0.4°C at 0°C
±0.9°C at 100°C
±1.4°C at 200°C
Display
4 readings per second nominal display update rate
4 digit LCD, 0.5" H
5 character 0.25" H alphanumeric
Low battery voltage indication(ALARM1 under range indication on display, ALARM2 over range indication on display)
Sensor
IEC-751 Class B 100 Î© Platinum RTD, 0.00385 alpha curve 1 /2" NPT male, 316L stainless steel
All wetted parts are 316L stainless steel
Spring-loaded probe (thermowell required for spring-loaded versions)
Controls and Functions
4 button front keypad for setup, calibration, and configuration.
Multi-level user-defined pass codes to prevent unauthorized changes.
Pass code optional for output test and set point changes.
Pass code required for configuration and calibration.
Output Test Function
Test mode to toggle alarm relays
Output test function can be pass code protected
Relay Output
Two independent SPDT relays 0.5A/115VAC, 1A/24VDC, non-inductive
Alarm status updated 4 times per second nominal
Alarm configuration mode can be pass code protected
Each alarm programmable for either HI or LO set point
Each alarm programmable for deadband in degrees
Selectable upscale or downscale burnout
Selectable normal or reverse alarm action
Factory defaults: °F temperature scale, SP1 HI, SP2 LO, 1° deadband, downscale burnout, normal alarm action, configuration and test mode not pass code protected.
3 ft long, 6-conductor 22 AWG cable for relays
Calibration
User settable pass code required to enter calibration mode
Zero and span temperature calibration
Non-interactive zero, span, and linearity, ±10% of range
Power
8 to 24 VAC 50/60 Hz or 9 to 32 VDC
Reverse polarity protected
3 ft long, 2-conductor 22 AWG cable for power
Weight
Product: 12 ounces (approximately)
Shipping: 1 pound (approximately)
Housing Materials ABS/polycarbonate NEMA 4X case, rear gasket, polycarbonate label, aluminum sensor block
Storage Temperature 40 to 203°F (40 to 95°C)
Operating Range 4 to 185°F (20 to 85°C) at housing
Cable Length 2.5"

Write a Review

0 Reviews Hide Reviews Show Reviews

Range	58.0 to 392.0°F or 50.0 to 200.0°C, selectable
Resolution	0.1 degree resolution
Typical Accuracy	Includes linearity error and ±1 LSD 11-point linearization ±0.7°C at 50°C ±0.4°C at 0°C ±0.9°C at 100°C ±1.4°C at 200°C
Display	4 readings per second nominal display update rate 4 digit LCD, 0.5" H 5 character 0.25" H alphanumeric Low battery voltage indication(ALARM1 under range indication on display, ALARM2 over range indication on display)
Sensor	IEC-751 Class B 100 Î© Platinum RTD, 0.00385 alpha curve 1 /2" NPT male, 316L stainless steel All wetted parts are 316L stainless steel Spring-loaded probe (thermowell required for spring-loaded versions)
Controls and Functions	4 button front keypad for setup, calibration, and configuration. Multi-level user-defined pass codes to prevent unauthorized changes. Pass code optional for output test and set point changes. Pass code required for configuration and calibration.
Output Test Function	Test mode to toggle alarm relays Output test function can be pass code protected
Relay Output	Two independent SPDT relays 0.5A/115VAC, 1A/24VDC, non-inductive Alarm status updated 4 times per second nominal Alarm configuration mode can be pass code protected Each alarm programmable for either HI or LO set point Each alarm programmable for deadband in degrees Selectable upscale or downscale burnout Selectable normal or reverse alarm action Factory defaults: °F temperature scale, SP1 HI, SP2 LO, 1° deadband, downscale burnout, normal alarm action, configuration and test mode not pass code protected. 3 ft long, 6-conductor 22 AWG cable for relays
Calibration	User settable pass code required to enter calibration mode Zero and span temperature calibration Non-interactive zero, span, and linearity, ±10% of range
Power	8 to 24 VAC 50/60 Hz or 9 to 32 VDC Reverse polarity protected 3 ft long, 2-conductor 22 AWG cable for power
Weight	Product: 12 ounces (approximately) Shipping: 1 pound (approximately)
Housing Materials	ABS/polycarbonate NEMA 4X case, rear gasket, polycarbonate label, aluminum sensor block
Storage Temperature	40 to 203°F (40 to 95°C)
Operating Range	4 to 185°F (20 to 85°C) at housing
Cable Length	2.5"
