STB 5-15 kV AC/DC Voltmeter Cable with Meter Probe 50103-G-02
STB 5-15 kV AC/DC Voltmeter Cable with Meter Probe 50103-G-02 Probe Tip, Shepherds Hook, 3 Hot Sticks, Large Case The High Line Voltmeter is a portable instrument for measuring AC voltages quickly and easily.It is lightweight and easy to use. The lineman or operator is not exposed at any time to high voltage. This instrument is light, compact and a time saver. The instrument is intended to be used with standard quick change hot sticks.It is typically used to measure voltage between ground and the line or bus connector.The Model 50103-G-01 High Line Voltmeter can be used safely on 21kV lines. The positive action selector switch makes the wide range of the voltmeter easily accessible.The test set is furnished complete with a standard 20-foot length ground lead, a 3kV proof tester,and padded carrying case. Other ground lead lengths are available.Ranges 0-5kV and 0-15kV, switch selectable Input impedance: 36 megohms (approx.)Maximum operating temperature range: -20° F to +165° F (-30° C to +75° C)
STB 5-15kV AC/DC Voltmeter Cable with Meter Probe 50103-G-01STB 5-15kV AC/DC Voltmeter Cable with Meter Probe 50103-G-01 Probe Tip, Shepherds Hook, Standard Case Two-position toggle switch Portable...
STB 15-50kV AC/DC Voltmeter 50103-G-0850103-G-05 AC High Line Voltmeter 15 - 50 kV. Probe Tip, Shepherds Hook, Standard Case The Model 50103-G-08 High Line Voltmeter is a rugged, resistive type...
STB 15-25kV AC/DC Voltmeter 50103-G-05STB 15-25kV AC/DC Voltmeter 50103-G-05 Probe Tip, Shepherds Hook, Standard Case AC High Line Voltmeter 15 - 50 kV. The High Line Voltmeter is a portable...
