Simpson M14510141 4-1/2 BKLT, +5VDC PWR, 200VDC, 5V

Simpson M14510141 4-1/2 BKLT, +5VDC PWR, 200VDC, 5V

Write a Review
$225.93
Brand
SKU:
M14510141

Simpson M14510141 4-1/2 BKLT, +5VDC PWR, 200VDC, 5V

Simpson Electric M145 Offers

Adding to cart… The item has been added
Add to Wish List

Simpson M14510141 4-1/2 BKLT, +5VDC PWR, 200VDC, 5V

Simpson Electric M145 Offers

The Simpson M145 LCD Digital Panel Meter uses a 4.5-digit LCD display with a negative image red backlighting for increased readability. The 12-pin mating connector with 6" (15.24 cm) lead wires allows for easy installation. The DC voltage panel meter requires less than 0.7" (17 mm) behind the panel.

Features

  • 4.5-digit 0.5" (12.7 mm) LCD display with a negative image red backlighting provides increased readability
  • 12-pin mating connector with 6" (15.24 cm) lead wires allows for easy installation
  • Fit 3/64 DIN standard cutouts
  • User-selectable decimal point
  • Requires less than 0.7" (17 mm) behind the panel
  • 5 VDC backlight power

Specifications:

Operating Humidity0 to 85% non-condensing at 104°F (40°C)
DC Voltage Resolution100 mV
Display TypeLCD
Product Weight1 oz (28.3 g)
Housing MaterialABS
Power SourceDC
DC Voltage Measurement Ranges200 V
Maximum DC Voltage Input250 V
Sampling Rate3 samples/second
Operating Temperature32 to 131°F (0 to 55°C)
Storage Temperature14 to 140°F (-10 to 60°C)
Power Requirements+5 VDC

What's included with the Simpson Electric M145

  • Simpson M145 LCD Digital Panel Meter for DC voltage, 200 V
