Input Range

-20 mA to +20 mA

Maximum Over Range

± 10%
(= ± 27500 counts)

Resolution

0.8 µA

Input Response Time
(% of span/delta I/delta time)

99.9 %/19.9 µA/10 mS

Data Freshness

11 ms

DC Common Mode
Rejection

>-120 dB

AC Common Mode
Rejection

>-120 dB @ 60 Hz

Maximum Survivable Input

36 mA or 9 VDC

Maximum Operating
Common Mode Voltage

250 V

Accuracy

0.05% (10 µA)

Isolation: Optical

4000 V

Isolation: Transformer

1500 V

Isolation: Channel to Channel

250 V continuous
(1500 V transient)

DRIFT: Gain Temperature Coefficient

30 PPM/ °C

DRIFT: Offset Temperature Coefficient

15 PPM/ °C

Power Requirements

5 VDC (±0.15 ) @ 200 mA

Input Resistance - Single Ended

200 ohms (each channel)

Ambient Temperature:
 Operating
 Storage

-20 °C to 70 °C
-40 °C to 85 °C

Humidity

5-95%, non-condensing

Torque, hold-down screws

4 in-lb (0.45 N-m)

Torque, connector screws

5.26 in-lb (0.6 N-m)

Wire size range

22 to 14 AWG

Agency Approvals

UL, CE, FM, RoHS, DFARS; UKCA

Warranty

Lifetime
