GE ITI Current Transformer 24-801

GE ITI 24-801 Current Transformer CT, Indoor, Model: 24, Ratio: 800:5 A, Single Phase, 10 kV BIL, 60 Hz

Write a Review
$223.62
Brand
SKU:
24-801 GE ITI

GE ITI 24-801 Current Transformer CT, Indoor, Model: 24, Ratio: 800:5 A, Single Phase, 10 kV BIL, 60 Hz

These Instrument grade, window type current

Adding to cart… The item has been added
Add to Wish List

GE ITI 24-801 Current Transformer CT, Indoor, Model: 24, Ratio: 800:5 A, Single Phase, 10 kV BIL, 60 Hz

These Instrument grade, window type current transformers are used with ammeters in such applications as panel boards, control panels and engine generators. They can be supplied with leads or terminals and mounting brackets.

Features

  • UL recognized - file number E93779
  • CSA approved - file number LR89403
  • Meet requirements of IEEE C57.13
  • Units can be designed to meet the requirements of IEC-44-1
  • High accuracy and burden capability
  • Convenient mounting and wiring
  • Test certificates and certified test reports available

Application

  • Relaying and metering

General Specifications:

  • Frequency: 50-400 Hz
  • Insulation Level: 600 Volts, 10 kV BIL full wave
  • Window Diameter: 1.25", 1.63", 2.00", 2.50" & 3.13"

Product Main Specifications:

  • CT
  • Indoor
  • Model: 24
  • Ratio: 800:5 A
  • Single Phase
  • 10 kV BIL
  • 60 Hz
  • Single Ratio
  • Relay Class: C20
  • Metering Class: 0.3 B1.8
  • Rating Factor: 1.0
  • Window Diameter: 2.5

Specification Datasheet:
