Crompton 22-501 Current Transformer , Current Ratio - 500:5
Write a Review
Write a Review
Crompton
Crompton 22-501 Current Transformer , Current Ratio - 500:5
$104.09
- Brand
- Crompton
- SKU:
- 22-501
- Availability:
- Y
Crompton 22-501 Current Transformer , Current Ratio - 500:5
Application:
Relaying and metering
Frequency:
50 400Hz
Insulation Level:
600 Volts, 10kV BIL full wave
- Terminals are brass studs No. 8 32 with one flat washer, lockwasher and regular nut
- Multi-ratios available
- Order Mount ing bracket kit separately
- Approximate weight: 10 lbs
Specification:
- Catalogue Number: 22-501
- Current Ratio: 500:5
- V.A.for±1% class: C50
- Weight in lbs: 9
- Window Diameter: 1.63"
