Absolute Process Instruments API 1200 G _ Thermocouple in- put single alarm

Features with all optional accessories:

Automatic Cold Junction Compensation
Field Adjustable Set and Reset
Plug-In Design for Fast Installation
Input LoopTracker® and Alarm Status LEDs
Alarm Test, Optional Reset Button

Applications:

Process Limit Backup Alarm
Temperature Alarm
Over, Under, Out-of-Range Alarm

The API 1200 G are factory configured for a thermocouple input and provide alarm contact outputs. Heavy duty relay contacts allow the module to directly control high capacity loads.

The API 1200 G provides a single set point and reset point adjustment and DPDT relay contacts. The alarm output can be factory configured for HI or LO operation, non-latching or latching, normal or reverse acting. Top-accessible potentiometers are used to adjust the alarm trip and reset points.

LoopTracker and Alarm Status LEDs

API exclusive features include a LoopTracker LED that varies in intensity with changes in the thermocouple input signal. A red/green bi-color alarm status LED visually indicate alarm status. These LEDs provide a quick visual picture of your process at all times.

Output Test/Reset

API's exclusive functional test button can be used to verify the alarm and system operation. The output test button greatly aids in saving time during initial startup and/or troubleshooting. The HT latching option provides the additional function of unlatching the alarm when the reset button is pressed. The alarm will reset if the alarm condition not longer exists.

Specifications Table:

Input	Most Thermocouple Types
Output	One 8 Amp DPDT Relay or Two 8 Amp SPDT Relays
Thermocouple Input	Factory configured, please specify thermocouple type and temperature range in °F or °C J, K, T, E, R, S, N, B, C, D, G, M, P Full ANSI temperature ranges Note: 100°F (55°C) is the recommended minimum span Consult factory if a smaller span is required
Cold Junction Compensation	Automatic for specified thermocouple
T/C Burnout Protection	Upscale burnout protection standard
T/C Current	Less than 1.0 µA, including burnout sense
Relay Output	Two SPDT form C contact sets operating in unison as one DPDT contact set One set point, 12 turn potentiometer, 0-100% of span One reset point, 12 turn potentiometer, 0-100% of span Factory configured alarm type Standard: HI alarm, non-latching, normal acting Options: LO alarm, latching, reverse acting
Relay Contact Rating	8 A at 240 VAC resistive load or 30 VDC resistive load 5 A at 240 VAC inductive load (cos f = 0.4) 3.5 A at 30 VDC inductive load (L/R = 7ms) See graph on other side for relay load ratings Caution: Do not exceed socket voltage rating Use an RC snubber for inductive loads
Output Test/Reset Button	Toggles relay(s) to opposite state when pressed
Response Time	300 milliseconds typical
Ambient Temperature Range and Stability	10°C to +60°C operating ambient Better than ±0.02% of span per °C stability, calculated, not tested
Housing	IP 40, requires installation in panel or enclosure API 011 or API 011 FS socket
Sockets	Socket mounts to 35 mm DIN rail or can be surface mounted
Power	115 VAC ±10%, 50/60 Hz, 2.5 W max
